Dia Base Rotatable Wood Burning Stove

Harrie Leenders have now launched the floor-standing model called the ‘DIA BASE’ which is supported on a robust steel foot.

Harrie Leenders Dia BaseRotatable Wood Burning Stove

The familiar Harrie Leenders DIA is a minimally styled, wall mounted rotating stove. It provides a wide panoramic view of the fire and has a nominal output of just over 5kW which makes it ideal for bringing spectacular Harrie Leenders style to smaller spaces.

Harrie Leenders Dia Base Rotatable Wood Burning Stove

Harrie Leenders have now launched the floor-standing model called the 'DIA BASE' which is supported on a robust steel foot. The stove has a maximum rotation of 360° and can either be anchored directly to the floor through the base flange or secured to a 750mm diameter circular floor plate (optional extra) which requires no further fixing to the floor.

According to Bart Leenders, the new design grew out of a customer request. "A customer asked us if we could build him a DIA on a base. So we started building. The result surprised us, because it looked like it had never been different, as the if the DIA had always had a foot".

TECHNICAL SPECIFICATION

NOMINAL OUTPUT: 5.4kW (Min 2.5kW Max 7.5kW)
GROSS EFFICIENCY: 71.7% (78.8% Nett)
FUEL TYPE: Any dry wood based fuel
APPLIANCE TYPE: Dry system
HETAS APPROVED: NO
AREA HEATED @ -1°C: 75m3 (2700 FT3) Approx.
FLUE SIZE: 150mm



Dimensions:
Height - 1100mm
Width - 760mm
Depth - 430mm
Weight - 120kg approx
