Bionic Fire Wood Burning Stove

With Bionic Fire, RAIS has realised its dream of creating an extraordinary eco-friendly or, as it is called, “green” stove. Wood combustion generates different types of particulates which – in unburned condition – are not desired in the environment. By means of pioneering and innovative development work, RAIS has managed to develop a technology that burns practically all residual particulates. Bionic Fire’s combustion technology simultaneously ensures that wood is utilised almost completely. This saves fuel and makes the stove financially advantageous for the user.

Rais Bionic Fire

Operating Bionic Fire is very simple. You put in wood and light the fire - the stove will take care of the rest. Air control is automatic, so you do not have to think of regulating anything - it can't get any more simple than that.
When a fire is lit in the top fire chamber, the smoke goes upwards as in other stoves. When the top chamber reaches the right temperature, the automatic control ensures that the draught changes leading the smoke into the bottom fire chamber. So the flames burn quietly in the top chamber and with much greater enthusiasm in the bottom one.


Rais Bionic Fire

Bionic Fire is available in two colours, each of which is a fantastic match for the black and white door.

It is this reverse combustion that effectively incinerates the last remaining particulates. At the same time, the long passage of the smoke through the stove results in fantastic utilisation of the fuel's thermal energy.

Bionic Fire is available in two colours, each of which is a fantastic match for the black and white door.
The black as a sharp contrast to the white and in a way that really emphasises the door's organic design to the extent possible. A nickel colour that is a new colour in Rais' range signalling total purity and appearing to have a lavish colour depth that provides a good combination with the black and white of the door.
The handle is elegantly shaped to follow the stove's contours. The door is easy to open by means of a gentle turn of the handle. When you let go of the door again, it locks automatically.

TECHNICAL DATA

  • Nominal output 4.6 kW
  • Output (min-max) 3.5 to 5 kW
  • Heats (at 20ºC) 45 to 83 m2
  • Gross Efficiency 78.2 % (86% Nett)
  • Particulates: 0.6 g/kg

DIMENSIONS (L x W x H)

  • External dimensions 472 x 482 x 1252 mm
  • Fire chamber's internal dimensions 280 x 200 x 300 mm
  • Flue outlet 150 mm Ø


NOMINAL OUTPUT: 4.6kW
GROSS EFFICIENCY: 71.9% (86% Nett)
FUEL TYPE: Any dry wood based fuel
APPLIANCE TYPE: Dry system
DEFRA Smoke Control Exempt: YES
CE MARKED: YES
HETAS APPROVED: NO
AREA HEATED @ -1°C: 70m3 (2520 FT3) Approx.
FLUE SIZE: 150mm
